    With the continuous development of artificial intelligence since 2016, the application requirements of power management, power supply detection, power supply control, and power supply self-recovery have been continuously improved. The variety of portable electronic applications is increasing. At the same time, it has brought great challenges to various power managers. In the application of various voltage devices for controlling power supplies, major manufacturers are constantly striving to provide customers with more efficient, low energy consumption and low risk. Low-cost voltage management, detection, and control components.

    In addition to the advantages and disadvantages of the material, the high-frequency transformer is the key to the manufacturing process.

    1. Determine the parameters of the skeleton;

    2, the cross line must be taped to isolate;

    3. All winding requirements are flat and do not overlap as the principle;

    4, a single set of windings can be a monochromatic line, two sets of windings must be dip-lined with two-color lines or open lines to avoid pinning.

    High frequency transformer

    The principle of high-frequency transformer winding is flat and uniform:

    1. The dredging is completely evenly separated;

    2. The tight winding wire is even and tight;

    3. The two sides of the coil and the edge of the winding groove maintain a sufficient safety distance A, B;

    4. The edge of the tape is flush with the winding groove, the tape is not skewed, and it is not broken and not damaged;

    5. Tape must be applied under the line to keep the insulation across the material line and the bottom coil;

    6. The outermost tape is cut on the core combination surface, and the cutting place must be covered by the iron core;

    7. The length of the casing must be sufficient. One end extends into the safety tape of the bobbin and the other end extends out of the BOBBIN, but not near the PIN.
